DIGITUS Cat.7 Installation Cable S/FTP B2ca AWG 23/1 LSOH 100 m Orange

DIGITUS Cat.7 Installation Cable S/FTP B2ca AWG 23/1 LSOH 100 m Orange

Name: DIGITUS Cat.7 Installation Cable S/FTP B2ca AWG 23/1 LSOH 100 m Orange
SKU: AC0041665
Price: 1423 SEK
Availability: InStock

1 423 kr

Få kvar

Fre, 12 jun - tis, 16 jun

Hemleverans

Säker betalning

14-dagars öppet köp

Säljs och levereras av

Shopyourproduct

Produktbeskrivning

LAN Internet cable, twisted pair AWG23 S/FTP cat.7 wire 100 m 10 GB Ethernet ; Transmission frequency 1200 MHz ; Support PoE Power over Ethernet ; Cabling category: Cat. 7 ; Shielding type: S-FTP , overall braid and pairs shielded with metal foil ; CPR: Dca ; Length: 100 m ; Color: Orange ; Cable construction: 4 x 2 AWG 23/1 , stranded twisted pair ; Coating: LS0H ; Conductor: Pure annealed copper , AWG 23/1 wire ; Operating voltage: 72 V DC ; Areas of application: . Horizontal, vertical and campus cabling. IEEE 802.3an ; 100Base-T ; 1000Base-T ; 2.5GBase-T; 5GBase-T; 10GBase-T IEEE 802.5: 16 MB; ISDN; FDDI; ATM; PoE/PoE+/4PPoE; Certification: GHMT Type Approval (z5423b-19). Standards: . ISO/IEC 11801 3rd Ed. ; SO 61156-5; TIA-568.2-D; EN 50173-1/4; EN 50288-4-1; Physical Properties: . Conductor: Pure annealed copper, AWG 23/1 wire; Insulation: SFS-PE (Foam-Skin Polyethylene); Number of insulated conductors: 8, twisted into 4 pairs; Color coding: Blue-white, orange-white, green-white, brown-white; Individual pair shielding: Aluminum foil providing 100% coverage; Full screen: Tinned copper braid; Outer layer: ECA to B2CA according to EN 50575; LSZH; Outer coating diameter: (nom.) 0.5 mm (ECA); 0.52 mm (DCA); 0.6 mm (CCA); 0.6 mm (B2CA); Outer coating color: Orange (RAL 2000); Mechanical properties: . Pulling force: 150 N max.; Minimum dynamic bending radius: 8 x AD mm min.; Minimum static bending radius: 4 x AD mm min.; Storage temperature range: -20 °C to +75 °C; Operating temperature range: -20 °C to +50 °C ; Installation temperature range: 0 °C to +50 °C ; Outer diameter: (nom. ) 7.0 mm (ECA); 7.2 mm (DCA); 7.5 mm (CCA); 7.5 mm (B2CA); Electrical properties: . Impedance: 100 15 Ohm 4-100 MHz; 100 25 Ohm 100-600 MHz; Capacitance: 45 pF/m nominal 1 KHz ; Capacitance unbalance with respect to ground: 1.6 pF/m max. 1 KHz ; Insulation resistance: 5 GOhm x km min. ; DC resistance: 95 Ohm/km max. (2% max. resistance unbalance); DC loop resistance: 190 Ohm/km max. (2% max. resistance unbalance); Operating voltage: 72 Vdc max. ; Link attenuation: CA-Type 1b ; Propagation delay: 450 nS/100 m max. ; Delay difference: 10 nS/100 m max. ; Distribution classification: d according to EN 50174-2 ; NVP: 79 % ;.

Färg

Orange

Artikel.nr.

bafdd3d6-0f24-5f41-aee7-2720e3530699

Egenskaper
Produktens färg	Orange
Kabellängd	100 m
Kabel standard	Cat7
Kabelskärmen	S/FTP (S-STP)
Anslutning 1	Nej
Anslutning 2	Nej
Typ, kontakt 1	Nej
Typ, kontakt 2	Nej
Jacka material	Low smoke zero halogen (LSZH)
Kabelform	Rund
Ledartyp	Solid
Kabelteknik	10GBase-T
Typ av ethernet-gränssnitt	2.5 Gigabit Ethernet, 10 Gigabit Ethernet, Snabb Ethernet, Gigabit Ethernet
AWG kabelstorlek	23/1
Frekvens	1200 MHz
Ursprungsland	Kina

Miljökrav
Temperatur vid drift	-20 - 50 ° C
Temperaturintervall (förvaring)	-20 - 75 ° C

Certifikat
Certifiering	CPR class B2ca

Förpackningens innehåll
Antal per förpackning	1 styck

Övrigt
Impedans	100 Ω

Logistikdata
Tulltaxa, kod för Storbritannien	85444920
