Maximal dataöverföringshastighet

100 Mbit/s

Antenn

(2) 2 dBi dual-band omnidirectional

Antennanslutning

RP-SMA

Antenn ökningsnivå (max)

2 dBi

Frekvensband

CC: 2.412-2.462 (1-11 channels); 5.180-5.240 (36-48 channels); 5.745-5.825 (149-165 channels); . EN: 2.412-2.472 (1-13 channels); 5.180-5.240 (36-48 channels); 5.260-5.320 (52-64 channels); 5.500-5.700 (100-140 (excluding 120, 124, & 128) channels); . RCR: 2.412-2.472 (1-13 channels); 5.180-5.240 (36-48 (excluding 38, 42 & 46) channels); 5.260-5.320 (52-64 channels); 5.500-5.700 (100-140 (excluding 120, 124, & 128) channels);

RF-exponering

FCC Bulletin OET-65C; RSS-102; EN 50385

Kommunikationsstandarder

IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.1xIEEE 802.3af

Externa anslutningar

1 RJ-45 auto-sensing 10/100 port(IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX), Duplex: half or full; 1 RS-232C serial console port

Kryptering/säkerhet

WPA, WPA2

Stödda protokoll

IEEE 802.11a High Speed Physical Layer in the 5 GHz Band; IEEE 802.11b Higher-Speed Physical Layer Extension in the 2.4 GHz Band; IEEE 802.11g Further Higher Data Rate Extension in the 2.4 GHz Band; IEEE 802.11i Medium Access Control (MAC) Security Enhancements Mobility

Strömförbrukning (vanlig)

5 W

Strömförsörjning

IEEE 802.3af PoE compliant or 5 VDC from available AC power supply

Temperatur vid drift

0 - 50 ° C

Omgivningstemperatur vid drift

32 - 122 ° F

Temperaturintervall (förvaring)

-40 - 80 ° C

Icke-fungerande relativ luftfuktighet (icke kondenserande)

5 - 95%

Elektromagnetisk kompatibilitet

EN 55022 Class B; EN 60601-1-2; EN 301 489-1; EN 301 489-17; ICES-003 Class B; FCC Part 15, Class B

Säkerhet

UL 2043; UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1

Certifiering

EN 55022 Class B; EN 301 489-1; EN 301 489-17; ICES-003 Class B; FCC Part 15, Class B

Vikt (imperial)

2.0 lb.

Produktstorlek (BxDxH)

127 x 139,7 x 33 mm

Vikt

910 g
