Finder 22.44.0.024.4410 Installationsskydd 4 NC 440 V/AC 1 st

Installation contactor for 35 mm rail, 4 NC contacts for 40 A / 440 V AC, contact material AgSnO2, max. switching power at 230 V AC: AC1-AC-7a: 16 kVA, rated current AC3-AC7b 22 A, glow and halogen lamps 4000 W, fluorescent lamps with EVG 1500 W, fluorescent lamps-uncompensated 1500 W, energy saving lamps 1000 W, LED (230 V AC) 1000 W, LV halogen lamps or LED with EVG 1000 W, NV halogen lamps or LED with KVG 1500 W. Coil 24 V AC/DC, Width 53.5 mm, mechanical switching position display, Relay protection type: IP 20 This text is machine translated.

Features

Highlights

• Installeringsskydd för 35 mm-skena
• 4 öppnare för 40 A/440 V AC
• Kontaktmaterial AgSnO²

leveransomfattning

• null
