Finder 7S.14.9.012.4220 Relä Nominell spänning: 12 V/DC Växelström (max): 3 A 1 st

Relay module with positively driven contacts according to EN 61810-3, type A. Basic component, suitable for safety applications that, if designed according to IEC/EN 62061 (IEC 61508), can achieve a safety integrity level of SIL 2. When the application is designed in accordance with ISO/EN 13849, a performance level of PL d can be achieved in machine and plant construction. 2 NO + 2 NC contacts for 6 A, contact material AgSnO2, supply voltage 12 V DC, LED status display of coil control, materials comply with EN 45545-2:2013 for fire protection in rail vehicles, tested according to EN 61373 (swinging and shocks, Cat. 1, Cl. B) and EN 50155 (cold, dry and heat, temperature class TX), with tension spring clamps, For mounting rail 35 mm (EN 60715), width 22.5 mm, protection class IP 20 This text is machine translated.
