Switch typ

hanterad

MIB stödd

Repeater MIB; Ethernet Interface MIB; IEEE 802.3 Ethernet MIB

Antal grundläggande RJ-45 Ethernet-portar

72

Konsolport

RS-232

Switch kapacitet

38,4 Gbit/s

Genomströmning

up to 22.4 million pps

Maximal överföringshastighet

0,1 Gbit/s

Paketbuffertminne

36 MB

Stöd för nätverksprotokoll

RFC 783 TFTP; RFC 1542 BootP; RFC 768 UDP; RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 2030 SNTP; RFC 2030 Simple Network Time Protocol; IEEE 802.3x Flow Control; DHCP Relay; RFC 3046 DHCP Relay Agent Information Option 82; RFC 3376 IGMPv1/v2/v3; IEEE 802.1D Spanning Tree; IEEE 802.1w Rapid Convergence Spanning Tree; IEEE 802.1s Multiple Spanning Trees; IEEE 802.3ad Link Aggregation Control Protocol; IEEE 802.1AB Link Layer Discovery Protocol; ANSI/TIA-1057 LLDP Media Endpoint Discovery (MED); RFC 2474 DiffServ Precedence; RFC 2598 DiffServ Expedited Forwarding (EF); RFC 2597 DiffServ Assured Forwarding (AF); RFC 2138 RADIUS; SSHv2 Secure Shell; Secure Sockets Layer (SSL); IEEE 802.1X Network Login; IEEE 802.1Q VLAN tagging; IEEE 802.1Q GVRP; IEEE 802.1p Priority; SNMPv1/v2c/v3; RFC 1493 Bridge MIB; RFC 1213 MIB II; RFC 2737 Entity MIB; RFC 2665 Ethernet MIB; RFC 2668 802.3 MAU MIB; RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3164 Syslog; XRMON; RFC 2613 SMON; RFC 2618 RADIUS Client MIB; RFC 791 IP; RFC 1757 RMON Groups 1,2,3,9; RFC 3176 sFlow

Stödda protokoll

General protocols HTML and telnet management IEEE 802.1AB Link Layer Discovery Protocol (LLDP); RFC 1757 RMON 4 groups: Stats, History, Alarms and Events; RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3164 BSD syslog Protocol; RFC 3176 sFlow; ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED); SNMPv1/v2c/v3; XRMON Network management MIBs Device management IP multicast IEEE 802.1D MAC Bridges; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1s Multiple Spanning Trees; IEEE 802.1w Rapid Reconfiguration of Spanning Tree; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3x Flow Control; RFC 768 UDP; RFC 783 TFTP Protocol (revision 2); RFC 791 IP; RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 854 TELNET; RFC 1542 BOOTP Extensions; RFC 2030 Simple Network Time Protocol (SNTP) v4; RFC 3046 DHCP Relay Agent Information Option Security RFC 1213 MIB II; RFC 1493 Bridge MIB; RFC 2613 SMON MIB; RFC 2618 RADIUS Client MIB; RFC 2665 Ethernet-Like-MIB; RFC 2668 802.3 MAU MIB; RFC 2737 Entity MIB (Version 2) QoS/Cos RFC 2474 DiffServ Precedence, including 8 queues/port; RFC 2597 DiffServ Assured Forwarding (AF); RFC 2598 DiffServ Expedited Forwarding (EF) IEEE 802.1X Port Based Network Access Control; RFC 2138 RADIUS Authentication; Secure Sockets Layer (SSL); SSHv2 Secure Shell RFC 3376 IGMPv3

Staplingsbar

Nej

Säkerhet

CSA 22.2 No. 950; UL 60950; EN 60950

Elektromagnetisk kompatibilitet

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; CISPR 22 Class A; EN 55024; IEC/EN 61000-3-2; IEC/EN 61000-3-3

Inbyggd processor

Ja

Processor

PowerPC MPC8245

Processorfrekvens

330 MHz

Internminne

64 MB

Flashminne

24 MB

Strömkälla

1 x J4839A

Ingående ström

3.8 - 8.2 A

Spänning

100-127 / 200-240 VAC

Strömförbrukning (vanlig)

630 W

Strömförsörjning via Ethernet (PoE) stöd

Nej

Management-Plattform

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (DB-9 serial port console); IEEE 802.3 Ethernet MIB; Repeater MIB; Ethernet Interface MIB

Latens

Latency: < 6 µs (FIFO)

Faktisk dataöverföringshastighet

10 Mbit/s

Produktstorlek (BxDxH)

388,6 x 442 x 133,4 mm

Anslutningsteknologi

Kabel

Minne och processor

Fabric: Motorola PowerPC MPC8245 @ 330 MHz, 24 MB flash, packet buffer size: 36 MB, 64 MB SDRAM

Externa anslutningar

2 open module slots; 72 auto-sensing 10/100 ports(IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX), Media Type: Auto-MDIX, Duplex: half or full; Supports a maximum of 120 auto-sensing 10/100 ports or 48 Gigabit ports or 8 mini-GBICs or 2 10-GbE ports, or a combination

Strömförsörjning

100-127 VAC/200-240 VAC; 50/60 Hz

Elektromagnetisk emission

FCC Class A; VCCI Class A; EN55022/CISPR-22 Class A; CISPR22 Class A; EN55024; IEC/EN61000-3-2; IEC/EN61000-3-3

Elektromagnetisk immunitet

EN 55024, CISPR 24; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2, IEC 61000-3-2; EN 61000-3-3, IEC 61000-3-3

Ledning produktnamn

HP ProCurve Manager Plus; HP ProCurve Manager (included)

Montage

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only.

Fjärradministration

command-line interface; Web browser; configuration menu; out-of-band management (DB-9 serial port console)

Vikt (imperial)

Fully loaded 23.81 lb.

Ingångsfrekvens

50 / 60 hz

Höjd vid drift (brittiska enheter)

up to 15000 ft.

Strömförsörjning slots öppna

1

Växla tyghastighet

33.6 Gbps

Temperatur vid drift

0 - 40 ° C

Temperaturintervall (förvaring)

-40 - 70 ° C

Omgivningstemperatur vid drift

32 - 104 ° F

Vikt

10,8 kg

Vikt inkl. förpackning

7,19 kg
