Säkerhetsrelä 1 st SFY3-DC24V Panasonic Driftspänning: 24 V/DC 3 NO, 1 NC (B x H x D) 28.6 x 14.5 x 39 mm

Safety relay with forced contacts. Minimal space required, low coil power loss and high switching current. Sealed relay after RTIII. Polarized rotating armature system enables a high shock and vibration resistance as well as a low coil power loss of 670mW nominally and only 241 mW holding power. Nominal switching capacity of 6A at 250VAC/24VDC. The relay has a clearance and creepage distance of ≥ 5.5 mm and thus a reinforced insulation between the contacts as well as between coil and contact load. Application: Security Modules and security controls, automation devices, machine control, elevators, escalators, emergency systems, railway systems, etc. This text is machine translated.
