Strömstötsrelä DIN-skena Finder 20.28.9.024.4000 2 NO 24 V/DC 1 st

Surge current switch for 35 mm rail, 2 NO contacts for 16 A / 250 V AC, contact material AgSnO2, max. switching power at 230 V AC: AC1 4000 VA, AC15 750 VA, glow and halogen lamps 2000 W, compensated fluorescent lamps 750 W, uncompensated fluorescent lamps 1000 W, energy saving lamps 400 W, LED (230 V AC) 400 W, LV halogen lamps or LED with EVG 400 W, LV halogen lamps or LED with KVG 800 W. Coil data 24 V DC, 5 W, 105 Ohm, width 17.5 mm, switching sequence: Off off / on off / off on, test button and mechanical switching position display, relay protection type: IP 20

This text is machine translated.

Features

Highlights

• Impulsbrytare för 35 mm-skena
• 2 slutare för 16 A/250 V AC
• Kontaktmaterial AgSnO²

leveransomfattning

• null
