Name: Amphenol T 3477 000 Rundkontakt Kontakt hane inbyggd Totalt antal poler: 7 Serie (rundkontakt): C091 1 st
SKU: 740046
Price: 248 SEK
Availability: OutOfStock

<h3>Amphenol T 3477 000 Rundkontakt Kontakt hane inbyggd Totalt antal poler: 7 Serie (rundkontakt): C091 1 st</h3> 3- 12-poliga kontaktdon med skruvförsegling och lödanslutning, invändig kabeldragavlastning och skärmning vid fastskruvad anslutning (EMC-säkerhet). Features<ul><li></li></ul> Highlights<ul><li></li></ul> leveransomfattning<ul><li></li></ul> OBS!<ul><li>Observera, öppet köp för ESD-känsliga komponenter &amp; förbrukningsmaterial gäller ej om originalförpackningen är brutet. Illustrerande bild. Illustration similar.</li></ul>

color

Egenskaper

Poltal

Anslutningstyp

To distinguish parts on a cable interface, connectors are grouped under genders. Sockets or jacks are considered to be female whilst plugs are referred to as male.

Kontakttyp

The colour e.g. red, blue, green, black, white.

Produktens färg

The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".

Egenskaper
Poltal	7P
Anslutningstyp	Rak
Kontakttyp	Hankoppling
Produktens färg	Silver
Internationellt skydd (IP) kod	IP40

Strömtillförsel
Ström	5 A
Spänning	300 V

Amphenol T 3477 000 Rundkontakt Kontakt hane inbyggd Totalt antal poler: 7 Serie (rundkontakt): C091 1 st

248 kr

248 kr

Produktbeskrivning
