Main circuit connection type

Screw connection

Actuating voltage type

AC

Overload release current setting

0.28 - 0.4 A

Degree of protection (NEMA)

Other

AS-i protocol support

Nej

INTERBUS protocol support

Nej

SERCOS protocol support

Nej

SUCOnet protocol support

Nej

SafetyBUS p protocol support

Nej

DeviceNet Safety protocol support

Nej

INTERBUS Safety protocol support

Nej

DATA-HIGHWAY protocol support

Nej

LON protocol support

Nej

DeviceNet protocol support

Nej

AS-i Safety at Work protocol support

Nej

PROFINET CBA protocol support

Nej

CAN protocol support

Nej

FOUNDATION Fieldbus protocol support

Nej

PROFIsafe protocol support

Nej

PROFIBUS protocol support

Nej

PROFINET IO protocol support

Nej

TCP/IP protocol support

Nej

Modbuss-protokoll

Nej

EtherNet/IP protocol support

Nej

Release class

Klass 10

Number of command positions

1

Suitable for emergency stop

Ja

Rated operational current (Ie)

0,4 A

Rated operational current (AC-3, 400V)

0,4 A

Temperature-compensated overload protection

Ja

Rated conditional short-circuit current (Type 1, 480Y/277V)

65 kA

Rated conditional short-circuit current (Type 2, 230V)

150 kA

Rated conditional short-circuit current (Type 2, 400V)

150 kA

Rated conditional short-circuit current (Type 1, 600Y/347 V)

30 kA

Suitable for rail mounting

Nej

External reset possible

Nej

Other bus system protocol support

Nej

Auxiliary/control circuit connection type

Screw connection

Short-circuit release

Ja

Omgivningstemperatur (max)

60 ° C

Coordination type according to IEC 60947-4-3

Klass 2

Höjd

203 mm

Förpackningens bredd

221 mm

Låddjup

306 mm

Förpackningens höjd

87 mm

Vikt inkl. förpackning

972 g

Minsta orderkvantitet

1 styck
