Phanteks NV7, med sin omisskännliga design, framhäver systemkomponenterna med moderkortet i centrum. Ett avgörande designelement hos NV7 är dess starka och definierande yttre ram som fångar och accentuerar hårdvarukomponenterna.

Med en ren design från alla håll låter NV7 dig placera ditt system fritt utan den traditionellt stökiga baksidan. Glaspanelerna erbjuder en nästan sömlös vy av insidan för att ytterligare fokusera på systemkomponenterna.

CASE DIMENSION (DXWXH): 532 x 253 x 586 mm

FORM FACTOR: Full Tower

MATERIALS: Steel Chassis, Tempered Glass front and side panels

MOTHERBOARD SUPPORT: ATX, micro-ATX, mini-ITX, SSI-CEB, E-ATX (up to 277mm wide)

FRONT IO: 1x USB 3.2 GEN 2 Type-C, 2x USB 3.0, D-RGB Mode button, D-RGB Colour button, D-RGB Speed button, D-RGB Channel button, Power button, Microphone/headphone Combo

CONNECTORS: Power SW (Power Switch), Power LED, USB 3.0, USB 3.2 GEN2 Type-E, HD-Audio, 2x D-RGB Channel A, 2x D-RGB Channel B, D-RGB Motherboard Input, 2X SATA Power

WINDOW: Yes, Front and Side Tempered Glass

EXPANSION

 PCI SLOTS: 8

INTERNAL 3.5” BAY: 2 (1x if all SSD positions are used)

INTERNAL 2.5” BAY: 6 (4x if both HDD positions are used)

VERTICAL GPU SUPPORT: Yes, with optional bracket PH-VGPUKT4.0_03R

 PACKAGING

PACKAGE DIMENSION: 690 x 345 x 628 mm

NET WEIGHT: 16.90 KG

GROSS WEIGHT: 19.35 KG

FANS

SIDE FAN: 4x 120 mm

BOTTOM FAN: 3x 120 mm / 3x 140 mm

TOP FAN: 3 x 120 mm

REAR FAN: 2 x 120 mm

RADIATORS

 SIDE RADIATOR: up to 360

BOTTOM RADIATOR: up to 360 / up to 280

TOP RADIATOR: up to 360

REAR RADIATOR: up to 240

CLEARANCES

GPU LENGTH: 450 mm

CPU COOLER HEIGHT: 185 mm

PSU LENGTH: 255 mm

SIDE 360 RADIATOR: Maximum size: 132 x 440 mm

SIDE 360 RADIATOR THICKNESS: 65mm (to GPU)

TOP 360 RADIATOR: Maximum size: 132 x 440 mm

REAR 240 RADIATOR: Maximum size: 132 x 320 mm

BOTTOM RADIATOR: Maximum size: 140 x 440 mm

SCOPE OF DELIVERY: NV7 D-RGB CHASSIS: 1x SSD/Cable bracket, 1x SSD/HDD bracket, 1x Two-channel D-RGB Controller, 1x Front-IO Module, Top LED Cover, Side LED Cover  ACCESSORY BAG/BOX: GPU Support bracket, 2x Airflow Covers, D-RGB MB Adapter, 6x Zip ties, Microfiber cloth, Screw Assortment Box
