Main circuit connection type

Screw connection

Number of auxiliary NC contacts

1

Actuating voltage type

DC

Rated operational power (AC-3, 400V)

5,5 kW

Suitable for distribution boards

Ja

Operating voltage AC (50Hz)

690 V

Operating coltage AC (60Hz)

690 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

12 A

Rated operation current (Ie at AC-1, 400V)

22 A

Rated operation power (NEMA)

8 HP

Rated operation current (Ie at AC-4, 400V)

8,5 A

Höjd

58 mm

Förpackningens bredd

50 mm

Låddjup

61,5 mm

Förpackningens höjd

77,5 mm

Vikt inkl. förpackning

294 g

Minsta orderkvantitet

1 styck
