Main circuit connection type

Screw connection

Number of auxiliary NC contacts

1

Number of auxiliary NO contacts

1

Actuating voltage type

DC

Rated operational power (AC-3, 400V)

15 kW

Suitable for distribution boards

Ja

Operating voltage AC (50Hz)

690 V

Operating coltage AC (60Hz)

690 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

32 A

Rated operation current (Ie at AC-1, 400V)

50 A

Rated operation power (NEMA)

20 HP

Rated operation current (Ie at AC-4, 400V)

22 A

Höjd

85 mm

Förpackningens bredd

54 mm

Låddjup

92 mm

Förpackningens höjd

115,5 mm

Vikt inkl. förpackning

611 g

Minsta orderkvantitet

1 styck
