Main circuit connection type

Screw connection

Number of auxiliary NC contacts

1

Number of auxiliary NO contacts

1

Actuating voltage type

AC/DC

Rated operational power (AC-3, 400V)

30 kW

Suitable for distribution boards

Ja

Operating voltage AC (50Hz)

690 V

Operating coltage AC (60Hz)

690 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

65 A

Rated operation current (Ie at AC-1, 400V)

80 A

Rated operation power (NEMA)

50 HP

Rated operation current (Ie at AC-4, 400V)

55 A

Rated control supply voltage (DC)

20 - 33 V

Rated control supply voltage (AC 50Hz)

20 - 33 V

Rated control supply voltage (AC 60Hz)

20 - 33 V

Höjd

114 mm

Förpackningens bredd

62 mm

Låddjup

122,5 mm

Förpackningens höjd

142 mm

Vikt inkl. förpackning

1,11 kg

Minsta orderkvantitet

1 styck
