Processortillverkare

AMD

Processorsockel

AM5-sockel

Kompatibla processorer

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Minnestyper som stöds

DDR5-SDRAM

Antal minnesplatser

4

Minnesplatser, typ

DIMM

Minneskanaler

Dubbla kanaler

ECC-kompatibilitet

ECC & icke-ECC

Minnesklockhastighet som stöds (max)

8000 MHz

Maximalt internminne

256 GB

Obuffrat minne

Ja

Typer av lagringsenheter som stöds

HDD & SSD

Lagringsenhetsgränssnitt som stöds

M.2, SATA III

Antalet hårddiskar som stöds

2

Antal lagringsenheter som stöds

6

RAID-stöd

Ja

RAID-nivåer

0, 1, 5, 10

Stöd för parallellprocessteknik

Stöds inte

USB 2.0 anslutning

2

USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar

1

USB 3.2 Gen 2 (3.1 Gen 2)-anslutningar

1

Antal SATA III kontakter

2

Ljudanslutning på framsidan

Ja

Kontakter på framsidan

Ja

ATX strömkontakt (24-pin)

Ja

CPU-fläktsanslutning

Ja

Antal kontakter för CPU-fläkt

1

Antal anslutningar för fläktar

3

Chassits genomgångsanslutning

Ja

EPS strömkontakt (8-polig)

Ja

12V-kontakt

Ja

Antal USB 2.0 anslutningar

2

Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar

4

Antal USB 3.2 Gen 2 (3.1 Gen 2) typ A-portar

2

Antal USB 3.2 Gen 2 (3.1 Gen 2) typ C-portar

1

Antal USB 3.2 Gen 2x2 typ C-portar

1

Antal LAN (RJ-45) anslutningar

1

Antal HDMI-portar

1

Antal Displayportar

1

Uttag för mikrofon/linje in

Ja

S/PDIF-utgång

Ja

WiFi-AP antennuttag

2

Nätverksansluten (Ethernet)

Ja

Typ av ethernet-gränssnitt

2.5 Gigabit Ethernet

Wi-Fi

Ja

Wi-Fi-standard

Wi-Fi 7 (802.11be)

Wi-Fi-standarder

Wi-Fi 7 (802.11be)

Bluetooth

Ja

Bluetooth-version

5.4

Moderkortets chipset

AMD B850

Ljudutgångskanaler

7.1 kanaler

Produktens färg

Vit

Komponent för

PC

Moderkort formfaktor

micro ATX

Moderkort, chipsetfamilj

AMD

Windows-operativsystem som stöds

Windows 11

PCI Express x16 (Gen 5.x) platser

1

Antal M.2 (M)-platser

4

BIOS-typ

UEFI AMI

BIOS minnesstorlek

256 mbit

Clear CMOS knapp

Ja

Förpackningens bredd

285 mm

Låddjup

277 mm

Förpackningens höjd

72,5 mm

Bredd

244 mm

Djup

244 mm

Antenn ingår

Ja

Ljudutgång

Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback*
Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
*A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Speciella egenskaper

Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports*
AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4/x2 mode)

AMD B850 Chipset
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4)
M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4) on the underside of the board

2 x SATA 6Gb/s ports
*Specifications vary by CPU types.

Andra funktioner

4 x DIMM slots, max. 256GB, DDR5
Supports up to 8000+MT/s(OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors
ECC and Non-ECC Un-buffered DIMM
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
ASUS Enhanced Memory Profile (AEMP)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.
**Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Grafikutgång

1 x DisplayPort**
1 x HDMI™ port***
* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
** Supports max. 8K@30Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI 2.1.
**** VGA resolution support depends on processors' or graphic cards' resolution.
