DIGITUS U/UTP Category 6 Cable PVC Eca AWG 23/1 500M Large bending radius and maximum flexibility for your network. 1GBit Ethernet ; 250 MHz ; PoE Power over Ethernet ; flammability class Eca ; 500m ; DIGITUS Category 6 U-UTP installation cables are manufactured and tested according to the specifications of ISO/IEC 11801, DIN EN 50173 and DIN EN 50288-5-1 Category 6 standards. Each cable consists of 8 polyethylene insulated cores with an AWG 23 color code. The information printed on the cable's outer jacket includes the brand name, item code and cable length. NVP: 69% ; Cable sheath: PVC ; Length: 500 m ; Category: CAT 6 ; Color: purple ; CPR: Eca ; Shielding: U-UTP, unshielded; AWG: 23 ; High-quality installation cable, conductors made of 100% copper. The cable (305m) is packed in a cardboard with a convenient hole for pulling out the cable. Cable for applications in IEEE 802.3: 10Base-T; 100Base-TX; 1000Base and IEEE 802.5: 16 MB; ISDN; ATM installations. Meets standards: ISO/IEC 11801 2 Ed. EN 50173; EN 50288-5-1 . Physical properties: Conductor: AWG 23/1, bare copper wire, diameter 0.57 mm nom.; Insulation: HD-PE; Number of total insulated conductors: 8, twisted in 4 pairs; Outer sheath: PVC; Outer sheath thickness: 0.50 mm nominal; Color: purple (RAL 4005); Mechanical properties: Tensile load: 150 N max.; Dynamic bending radius: 8x AD mm min.; Static bending radius: 4x AD mm min.; Temperature range during transport and storage: -20 to +60 °C; Operating temperature range: -20 °C to +75 °C; Temperature range during installation: 0 °C to +50 °C; Belt outer diameter: 6.0 mm nominal; .
