Switch typ

hanterad

Kommunikationsstandarder

IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

10G stöd

Ja

Switch kapacitet

14000 Gbit/s

Genomströmning

20000 Mpps

Rackmontering

Ja

Staplingsbar

Ja

Formfaktor

7U

Inbyggd processor

Ja

Processor

ARM Cortex-A72

Processorfrekvens

1800 MHz

Minnestyp

DDR4-SDRAM

Internminne

8000 MB

Flashminne

32000 MB

Strömkälla

AC

Strömförsörjning ingår

Ja

AC-inspänning

200 - 240 V

Meddelane om effektförbrukning

R0X35A PSU: 1800W at 200–240 VAC, 1100W at 110–127 VAC R0X36A PSU: 3000W at 200–240 VAC, 1500W at 110–127 VAC

Notering för strömförsörjning

Power supply units are not included; order separately. Supports four modular front‐serviceable power supplies with removable rear‐serviceable power cord inlet adapters. Supported power supplies: R0X35A, R0X36A. PoE available will be dependent on the number of management modules, line cards, fan trays and the number of power supplies used. Power supplies not included; order separately.

Strömförsörjning via Ethernet (PoE) stöd

Ja

Latens

1G: 5.32 μSec 10G: 1.48 μSec 25G: 2.78 μSec 40G: 1.31 μSec 100G: 1.42 μSec

Minne och processor

CPU Management Module: Quad-core Arm Cortex A72 at 1.8 GHz Line Cards: Dual-core Arm Cortex A72 at 1.8 GHz (R0X38A‐R0X45A and R0X38B‐R0X40B) Line Cards: Quad-core Arm Cortex A72 at 1.8 GHz (R0X38C‐R0X45C, S0E48A, S1T83A) Memory and flash Management Module: 16 GB DDR4 ECC memory: 32 GB eMMC Flash memory Line Cards: 4 GB DDR4 memory (R0X38A‐R0X45A and R0X38B‐R0X40B) Line Cards: 8 GB DDR4 memory (R0X38C‐R0X45C, S0E48A, S1T83A)

Externa anslutningar

High speed, non-blocking 1/10/25/40/50/100GbE ports 10 I/O module slots maximum depending on model

Prestandahantering

1 x RJ‐45 console port 1 x USB‐C console port 1 x OOBM port 1 x USB Type-A host port HPE Aruba Networking Management Software (AirWave) HPE Aruba Networking Central HPE Aruba Networking Switch Multi-Edit Software HPE Aruba Networking CX Mobile App Command-line interface SNMP v2c/v3 RMON

Vikt (imperial)

53,6 kg (118.2 lbs)

Fläkt

Two field replaceable system fan trays

Temperatur vid drift

0 - 45 ° C

Bredd

528,8 mm

Djup

442,6 mm

Höjd

448,5 mm

Vikt

53,5 kg
