USBASP USBISP AVR Programmer USB ISP USB ASP ATMEGA8 ATMEGA128

USB ISP Programmer for ATMEL AVR ATMega ATTiny 51 Board ISP Downloader

Features

Onboard ATMega8(L).
Onboard over-current protection.
List of supported chips :
51 Series: AT89S51, AT89S52,, AT89S53, AT89S8252
AVR Series: ATTiny12 (L), ATTiny13 (V), ATTiny15 (L), ATTiny24 (V), ATTiny25 (V), ATTiny26 (L), ATTiny2313 (V), ATTiny44 (V), ATTiny45 (V), ATTiny84 (V), ATTiny85 (V), AT90S2313 (L), AT90S2323 (L), AT90S2343 (L), AT90S1200 (L), AT90S8515 (L), AT90S8535 (L), ATMEGA48 (V), ATMEGA8 (L), ATMEGA88 (V), ATMEGA8515 (L), ATMEGA8535 (L), ATMEGA16 (L), ATMEGA162 (V), ATMEGA163 (L), ATMEGA164 (V), ATMEGA165 (V), ATMEGA168 (V), ATMEGA169 (V), ATMEGA169P (V), ATMEGA32 (L), ATMEGA324 (V), ATMEGA325 (V), ATMEGA3250 (V), ATMEGA329 (V), ATMEGA3290 (V), ATMEGA64 (L), ATMEGA640 (V), ATMEGA644 (V), ATMEGA645 (V), ATMEGA6450 (V), ATMEGA649 (V), ATMEGA6490 (V), ATMEGA128 (L), ATMEGA1280 (V), ATMEGA1281 (V), ATMEGA2560 (V), ATMEGA2561 (V), AT90CAN32, AT90CAN64, AT90CAN128, AT90PWM2 (B) , AT90PWM3 (B), etc.

This downloader is no more than 64K program restrictions. It perfectly support WIN7 64 bit systems and 32bit WIN98, WIN ME, WIN2000, WIN 2003, WIN XP, VISTA.

Support USB 1.0 or 2.0 interface
USB port power supply, output 20 ohm isolation resistors prevent short-circuit on the USB out of the target board can be powered with the same time with USB
Support S51 and the AVR chip programmer. fast and stable
Standard IDC 10PIN interface

Support software: AVR_FIGHTER, Progisp1.72

#USB ISP Programmer For ATMEL AVR ATMega ATTiny 51 Development Board
